码垛机器人常见故障及排除方法Common faults and troubleshooting methods of palletizing robots
在线咨询
  • 产品详情

码垛机器人常见故障及排除方法Common faults and troubleshooting methods of palletizing robots

码垛机器人常见故障及排除方法主要包括以下几个方面:

一、机械故障

  1. 六轴末端工具或物体与外部物体碰撞:这可能是由于码垛箱体变形、定位机构松动、胶块试教点错位或码垛机触摸屏参数设定错误等原因造成的。此时,机器人会停止预定路线的运行,并按防碰撞模型向相反方向运行一定距离以释放残余应力。解决方法包括检查并调整相关部件和参数。
  2. 润滑油粘度大导致动作监控触发:这通常是由于环境温度低造成减速机润滑油粘度大、启动性变差。应确保减速机润滑油温度在要求的范围内(一般为5℃-40℃)。

二、电气故障

  1. 动作监控触发故障:这可能是由于电机长期运行导致动、静摩擦片产生的粉末积聚并粘附在摩擦片上,增大摩擦阻力。解决方法包括适当增大电机最大扭矩或清洁摩擦片。
  2. 超程故障:这通常发生在试教期间,需要按照操作手册进行故障排除。

三、其他故障

  1. 夹钉动作太慢或夹钉行程不足:这可能是由于螺栓松动、前扣或板机内片磨损造成的。解决方法包括旋紧螺栓、更换磨损部件等。
  2. 活塞杆或扳机处漏气:这通常是由于相关部件损坏造成的,需要更换损坏的部件。

此外,还有一些日常维护和保养的注意事项:

  • 使用前要先预热设备,确保烫头温度达到工作要求。
  • 定期对机器人进行清洁和润滑,检查电气线路和连接器的完好性。
  • 遵循机器人的操作手册和保养指南,确保正确的使用和维护。

请注意,对于复杂的故障或需要专业知识的维修工作,建议联系专业的机器人维修服务商进行处理,以确保安全和有效的故障排除。

The common faults and troubleshooting methods of palletizing robots mainly include the following aspects:

1. Mechanical failure

Collision between the six-axis end tool or object and an external object: This may be caused by the deformation of the palletizing box, the loosening of the positioning mechanism, the misalignment of the test point of the glue block, or the wrong parameter setting of the touch screen of the palletizer. At this point, the robot stops the operation of the predetermined route and runs in the opposite direction for a certain distance according to the collision avoidance model to release the residual stress. The workaround includes checking and adjusting the relevant parts and parameters.
High viscosity of lubricating oil leads to action monitoring triggering: This is usually due to low ambient temperature, which causes high viscosity and poor start-up of lubricating oil in the reducer. It should be ensured that the temperature of the lubricating oil of the reducer is within the required range (generally 5°C-40°C).
2. Electrical faults

Motion monitoring triggers a fault: This may be due to the long-term operation of the motor, which causes the powder produced by the dynamic and static friction plates to accumulate and adhere to the friction plates, increasing the frictional resistance. Solutions include appropriately increasing the maximum torque of the motor or cleaning the friction plates.
Overtravel Failure: This usually occurs during the trial and needs to be troubleshot according to the operator's manual.
3. Other faults

Clamping the nail action too slowly or insufficient clamping stroke: This can be caused by loose bolts, worn front buckles, or the inner piece of the machine. Workarounds include tightening bolts, replacing worn parts, etc.
Air leakage at the piston rod or trigger: This is usually caused by damage to the relevant part, which needs to be replaced.
In addition, there are some precautions for routine maintenance and upkeep:

Preheat the device before use to ensure that the temperature of the ironing head meets the working requirements.
Regularly clean and lubricate the robot, check the integrity of electrical wiring and connectors.
Follow the robot's operating manual and maintenance guidelines to ensure proper use and maintenance.
Please note that for complex faults or repair work that requires specialized knowledge, it is recommended to contact a professional robot repair service provider to ensure safe and effective troubleshooting.
